Full-sensored Mode Supported
The 1st 1/8 scale competition ESC that'll work the full-sensored mode anyway
times (whenever combining it with a HOBBYWING matching engine).
Turbo Timing Technology
Turbo timing technology is implemented by the XR8 SCT to unleash many power
of a HOBBYWING matching engine.
Small & Light construction Design
Small (30.1per cent smaller versus XR8 Plus in proportions) and light (36.5g lighter than XR8
Plus in fat) framework design especially simplifies producing
the power system (esp. for cars like buggy and touring car
with compact framework).
Programming / Upgrading /
information reading wirelessly
With Hobbywing's "WiFi Express" module and iPhone or an Android os phone (aided by the HOBBYWING
WiFi Link pc software set up), the client can from another location plan parameters, update firmware and
always check relevant information about the ESC without making the control stand.
Coasting
The XR8 SCT provides a smooth off-throttle coasting function, which simulates the impression
of inertia and power of a large-scale automobile driving experience. This may greatly boost the
performance of builds using big, high-powered motors as electromagnetic drag
becomes a great aspect in unforeseen deceleration whenever in off-throttle
place, adversely impacting driving performance and basic maneuvering.
Capacitor Thermal Protection
Capacitor thermal protection implemented by the XR8 SCT will efficiently prevent capacitors
from exploding and causing irreversible problems for the ESC as a consequence of overload.
Tall Voltage incorporated BEC
High voltage included BEC with a production up-to-date completely to 15 Amp and a
switchable production voltage of 6V-7.4V allows users to
utilize various high torque and high voltage servos.
Tall Reliability & Durability
Built with tough and top-notch elements as well as in combination with cutting-edge firmware,
the XR8 SCT can deliver unmatched energy and satisfaction possibly the absolute numerous hardcore
of rushing applications, it will continually be responsive enough to shield it self from harm due
to overloading as a result of genuine punishment, overuse and/or particular mistake.
Advanced and Secure Electronic Switch
Electronic switch with a lifespan of over 50000 on/off rounds, housed in a totally waterproof,
dust-proof and shock-resistant design.
Ultra-Reliable Cooling System
HOBBYWING's patented air-con technology makes use of proprietary heat-conductive copper
bars to quickly and efficiently get all interior temperature through MOSFET board in direction of
included CNC machined billet aluminum heatsink housing. The cooling fan adopts a
shockproof mounting which effectively reduces the possibility
of fan damage considering vehicle’s regular jumps.
Wide applicability
This XR8 SCT ESC isn't only highly relevant to 1/8th buggies and short-course
cars and 1/10th short-course automobiles, automobiles and monster cars.
Item Specification
Type
- Scale : 1/8th&1/10th
- Brushed/Brushless : BL
- Sensored/Sensorless : SD
- Waterproof : No
Specifications
- Cont./Peak Present : 140A/880A
- Input Voltage : 2-4S Lipo/6-12 Cell NiMH
- BEC production : modification Mode: 6V/7.4V,6A
Wires & Connectors
- Input Wires : Red-12AWG-200mm*1/Black--12AWG-200mm*1
- Output cables : Blue -12AWG-200mm*1
Yellow-12AWG-200mm*1
Orange -12AWG-200mm*1 - Input Connectors : No
- Output Connectors : No
Fan
- Size : 30x30x10mm
- Voltage quantity : 5-7.4V
- Powered by : BEC
ESC Programing via
- SET Button on ESC : perhaps not Supported
- LED Program Box : maybe not Supported
- LCD Program Box : Supported
- WiFi Module : Supported
- Program Port : PRG/Fan Port
Firmware
- Firmware Upgrade : Supported
Size & Weight
- Size : 54.1x37.2x36.1mm
- Weight : 90.5g
Applications
- Motors : SL BL Motors
SD BL Motors - Vehicles : 1/10th SCT/Truck/Monster Truck & 1/8th Buggy/On-road Racing
- KV Rating/T Count : With 2S LiPo/6S NiMH: 3660 size engine, KV≤6000
With 3S LiPo/9S NiMH: 3660 size engine, KV≤4000
With 4S LiPo/12S NiMH: 3660 size engine, KV≤3000
With 4S LiPo/12S NiMH: 4268 size engine, KV≤2500.
