Specs:
- Settings: Forward/Brake/Reverse
- Input Voltage: 2S-3S lipo
- BEC: 6V/7.4V selection/max ~5A
- motor limitation: 4.0T or more
- Max offer: ~200A per period
- Size: ~30.5x38x16mm
- fat: ~38g (maybe not add wiring and fan)
Hardware:
* Change to 32-bit MCU with ultra-smooth, faster reaction with accurate throttle and stopping control. More high end energy using the identical product function setup when compared with Radon expert V4.1.
* unique PCB design and unique inside gear design raise the temperature dissipation and may also be around 10'C below radon specialist v4.1 centering on an identical condition. The price control cooling fan are eliminated whenever operating little to moderate track for modify/stock race.
* relate to outside Bluetooth product for higher level development and firmware modification through mobile phone APPS. APPS will undoubtedly be on both IOS and Android os os os.
* real-time Data research through mobile APPS(active Input & manufacturing Throttle, Temperature, RPM, Adv. Timing, Voltage and min. voltage, Max Temperature, RPM & Adv. Timing)
* included one touch On/Off switch which help outside On/Off switch.Limit version casing with Metallic golden color in available line
Features:
- 32bit-MCU with ultra-smooth, precise throttle and stopping control
- perfect for sensored/sensorless brushless machines
- relate to Bluetooth item for advanced development and firmware modification through Cellphone APPS (support Android os os os or Apple)
- genuine information Analysis through cellphone APPS(Max, RPM, RPM, Advance Timing, Max Timing, Temperature, Max Temperature, minimal Voltage minimal voltage and ESC temperature)
- built-in one touch On/Off switch which help external On/Off switch
- Bulit-in Low voltage cut-off, Overheat security and indicator loss security
-Ext. Bluetooth is optional and is not within the package.
