XRAY 370008 X12 2018 US Specs  [XR-370008]

Dimensions

• Class: 1/12 electric pan car
• Width: Adjustable 167mm +/- 2mm front component, 169mm rear
• Length: 264mm (varies centered on right back tires utilized)
• Wheelbase: 201 +/-0.5mm
• Weight: 202 g
• Ready-to-run fat: 840 g - incl. BL system (varies according to gear used)

Chassis

• Chassis: EU variation - 2.5mm carbon fiber, CNC machined; usa variation - 2.0mm Swiss 7075 T6 aluminum, CNC machined
• Body: maybe not included, utilizes 1/12 pan car sort

Drivetrain

• Type: 2WD direct drive to rear axle
• Rear Axle: Graphite shaft with ball differential
• Primary: Spur/pinion
• Bearings: High-speed ball-bearings (10)

Suspension

• Front: Spring-supported, kingpin-style front suspension system system with upper & paid down suspension system system system system fingers and steering blocks
• back: Articulating right back engine POD adjustable via pivot-ball links, handled by rear surprise absorber.
• Rear Shock: Central adjustable oil-filled shock absorber

Geometry

• Ride Height: Adjustable front + back
• Wheelbase: Adjustable
• Camber Adjustable front
• Front Caster (Static): 1–14.5° fixed adjustable fixed caster
• Front Caster (Reactive) 2.5–7.5° adjustable reactive caster
• Track-width: Adjustable front component and rear
• Toe: Adjustable front
• Downstop: Adjustable rear
• Ackermann: Adjustable with shims
• Bumpsteer: Adjustable with shims
• Steering: Direct linkage between steering servo saver and steering obstructs
• Balance: Front/rear weight stability adjustable via battery spot

Other

• Wheels: maybe not included
• Tires: not included
• guidelines: Full-color guide with 3D visuals
• Set-up guide: imprinted variation maybe not included. Latest full-color Set-up guide (16 pages) are put up from XRAY web page. Set-up Book shows past XRAY models in photographs included within it, nevertheless the methodology and set-up concept are the same for many 1/12 pan vehicles.
• Packaging: Carton package with artificial bags with parts
• Additionally included: HUDY Diff Grease, Authentication Certificate, elements list & exploded view, decals, oils
• Not included: motor, batteries, cost controller, tires, human anatomy, steering servo, radio gear, tools
