XRAY X12



2019 All-new Specs

  • All-new EU and United States Edition both created & optimized for specific traction conditions
  • All-new EU Edition is optimized for low-, medium-, and high-traction conditions
  • All-new United States Of America Edition is optimized for high- and very-high traction conditions
  • All-new 2.5mm graphite framework for EU Edition with battery backstop grooves
  • All-new 2.0mm Swiss 7075 T6 aluminum framework with battery pack backstop grooves
  • All-new right back wheelbase adjustment
  • All-new top clamps with composite bushing for better durability
  • All-new bulkheads use groundbreaking top clamps
  • All-new graphite back brace with vital backstop and O-ring battery power mount system
  • All-new O-ring for securing the battery
  • All-new adjustable graphite battery power backstop with 4 positions
  • All-new longer front side part component graphite bumper owner



General

  • XRAY 1/12 pan-car with authentic 100per cent self-developed XRAY elements, produced and manufactured by XRAY in Europe
  • Legendary XRAY premium design, workmanship & item quality and unmatched comprehension of top details
  • Simple yet effective and proven design, well thought-out details, unmatched accuracy of tiny details
  • High-competition design with consider ultra-low fat, causing super-lightweight construction
  • Optimized for interior carpeting rushing additionally outside asphalt rushing



Chassis

  • EU Edition featuring CNC-machined framework from rigid custom-manufactured 2.5mm high-grade graphite item with specially-designed substance for carpeting and asphalt racing
  • US Edition featuring CNC-machined framework from premium 2.0mm Swiss 7075 T6 aluminum material
  • Chassis & back pod function pre-drilled centerline holes for maximum fat security modification using HUDY Balancing Tool #107880
  • Chassis includes holes and grooves for composite electric batteries backstops
  • Body articles with fully-adjustable human anatomy holders; optional super-fine +1 or +2mm human anatomy backstops made for additionally body height adjustment
  • Chassis design permits either horizontal or right battery pack placement
  • Chassis design enables to change directly power packs placement
  • Chassis design permits to change one of several secrets wheelbase



Front suspension system system:

  • High-competition, fully-adjustable front suspension system system system system system with super-clean design of composite suspension system parts
  • EU Edition featuring front part paid down & top hands and steering obstructs created from hard product to make the vehicle safer to use a vehicle and offer smoother steering
  • US Edition features unique graphite suspension system system fingers that decreases torsional flex regarding the fingers in the corners of very-high traction songs, making the automobile more reactive and a lot more an easy task to drive
  • Shims included for adjusting top supply position
  • Precision steering block and front top ball bones to have additional accurate steering
  • Bumpsteer shims for enhanced steering
  • Lower suspension system system system system system hands function smart eccentric aluminum inserts for fast & easy track-width adjustment
  • Optional aluminum 0.5mm and 1.0mm eccentrics for developing track width
  • Ride height modification shims for quick, exact, and hassle-free journey height modification for different track conditions. Quantity 0.2, 0.4, and 0.6mm trip height modification shims are included.
  • fast & simple front component caster modification via included clips
  • All composite elements manufactured by XRAY utilizing premium self-developed composite mixtures which guarantee perfect flex with this specific suspension system system elements yet hard sufficient to withstand hefty crashes
  • Reactive caster modification (preset 2.5°, 5.0° or 7.5°) via easy-to-change eccentric bushings
  • Ultra-precise wheel axles CNC-machined from premium HUDY Spring Steel™ also hardened and hand ground for precision fitment
  • High-precision, HUDY Spring Steel™ top pivot balls guarantee super-fine motion of front component suspension
  • Composite repaid pivot balls for smooth front suspension system system system movement
  • Lightweight front top 3mm adjustable HUDY Spring Steel™ camber turnbuckles can withstand hefty crashes
  • Quick & easy wheelbase modification by going the whole front component suspension system system system in framework 2mm front part or right back



Steering:

  • Unique adjustable servo mount can accommodate several kinds of 1/12 servos, and enables modification of servo to chassis centerline
  • Floating servo wont touch framework, eliminating undesired tweak
  • Super-tiny yet robust steering obstructs with specially-designed axles prevent axle rotating while tightening the wheel locknuts
  • Pivoting front suspension system system system system system has super-smooth hardened metal kingpins supported by soft springs. Optional medium, difficult, and extra-hard suspension system springs available.
  • Tiny yet robust servo saver with effortless Ackermann modification via included shims
  • 4-spring servo saver for accurate, smooth steering
  • Specially-designed slim composite ball joints
  • Adjustable, super-lightweight Swiss 7075 T6 aluminum turnbuckles



Straight Back pod:

  • Compact, ultra-lightweight slim straight back pod contains high-strength aluminum bulkheads, graphite brace, and strong high-grade 2.5mm graphite plates
  • Unique aluminum bulkheads and top bulkhead clamp are CNC-machined from premium extra-hard Swiss 7075 T6 aluminum, furthermore black colored colored coated for very long life & trendy look
  • Optional eccentric top clamps allows to change right back wheelbase
  • Light, small pod pivot ball decreases the body fat of going elements and escalates the movement choice of a big part pod plate
  • Optimized backside pod url positions
  • Rear pod top dinner includes mounting opening for optional component shock (for different damping traits)
  • Premium-grade graphite top deck provides solid accessory for shock absorber to rear pod
  • Premium graphite straight back url brace holds the medial component pipes alongside component springs and body posts
  • Premium graphite right back hyperlink brace allows to set up graphite adjustable battery power backstop and features grooves the O-ring which secures the battery
  • Super-easy motor top access
  • Rear pod accommodates all motors
  • Ride height shims for ultra-fine straight back trip height adjustment
  • Rear differential features high-grade precision carbide balls (for spur gear), hardened and precision-ground steel D- shims, and premium carbide 3x8mm axial thrustbearing
  • Ultra-lightweight graphite straight back axle
  • Precision-molded spur gear produced from XRAY's exclusive composite product, ensuring genuine running, super-quiet procedure, super lightness and robustness for managing effective motors
  • Aluminum straight back hubs machined from lightweight aircraft aluminum, especially lightened and black-coated for trendy look
  • Lightweight back wheel mounting screws for reduced rotating weight
  • Aluminum backside left wheel hub with center-balanced clamping mounting system, ensures safe mounting while eliminating vibration and run-out
  • Easy right back track-width modification via included shims
  • Rear human body articles are create towards framework via a thorough independently-mounted graphite owner, ensuring body downforce is precisely based in the chassis
  • Rear pod fat security is modified via shims between motor and bulkhead
  • Straight component springs do have more constant and smoother compression for better out-of component making and reimbursed traction rolling



Shock:

  • XRAY micro shock with comparable design to its “big brother” counterpart in XRAY’s effective T4 touring automobile platform
  • Centralized shock absorber position
  • 4 frontward, 4 rearward surprise location choices
  • Fully-adjustable shock with hard-anodized aluminum shock human anatomy for superior durability, not forgetting black-coated for fashionable look
  • Fine-threaded shock body for fast & easy surprise springtime preload adjustment
  • Tiny, slim surprise membrane provides super-smooth damping faculties
  • Super-soft silicone surprise O-ring for smooth procedure, and improved sealing
  • Ultra-finely finished shock shaft with precise-molded composite shock piston guarantees optimal oil movement and smooth surprise absorber action
  • Simple yet smart shock construction allows fast & painless shock-length modification for downstop
  • Shock destination modification via shimming of mounting ball studs
  • Rear pod component protection handled by component pipelines which give equalized lateral damping both in instructions while eliminating unwelcome rebound
  • Rigid centrally-mounted shock mount prevents tweak, and specially improves lateral stability
  • 1-hole piston for enhanced damping characteristics
  • Shock size adaptor is roofed to boost surprise size



Assembly & assist:

  • Highest quality composite elements verify super-precise fitment, effortless make, and smooth procedure of parts
  • Premium 3D full-color Instruction Manual
  • Exclusive Virtual Online Setup Sheet database with countless set-up sheets for competition tracks around the world
  • Premium, unmatched XRAY on the internet assistance



Modification opportunities:

  • Front camber, caster, and toe
  • Front & backside wheelbase
  • Front & backside track-width
  • Front, center, and right back journey height
  • Front springs
  • Central shock absorber size & position
  • Downstops
  • Pod damping
  • Bumpsteer
  • Weight balance
  • Ackermann
  • Front brace stiffness
  • Differential setting
  • Servo place
  • Battery position



Specs:



Measurements

Course:

1/12 electric pan automobile

Width:

Adjustable 167mm +/- 3mm front part component

Length:

264 mm (varies devoted to right back tires used)

Wheelbase:

201+/- 0.5mm

Bodyweight:

205 g

Ready-to-run fat:

840 g - incl. BL system (varies centered on gear utilized)

Framework

Chassis:

EU variation - 2.5mm carbon fibre, CNC machined

Usa variation - 2.0mm Swiss 7075 T6 aluminum, CNC machined

Body:

Not included, utilizes 1/12 pan vehicle type

Drivetrain

Type:

2WD direct drive to rear axle

Right Back Axle:

Graphite shaft with ball differential

Principal:

Spur / pinion

Bearings:

High-speed ball-bearings (10)

Suspension System

Front Side:

Spring-supported, kingpin-style front suspension system system system with top & paid off suspension system system system arms and steering obstructs

Rear:

Articulating straight back engine POD adjustable via pivot-ball links, handled by back shock absorber

Back Shock:

Central adjustable oil-filled surprise absorber

Geometry

Ride Height:

Adjustable front + back

Wheelbase:

Adjustable

Camber:

Adjustable front component

Front Caster (Static):

1–14.5° static adjustable fixed caster

Front Caster (Reactive):

2.5–7.5° adjustable reactive caster

Track-width:

Adjustable front part and right back

Toe:

Adjustable front

Downstop:

Adjustable right back

Ackermann:

Adjustable with shims

Bumpsteer:

Adjustable with shims

Steering:

Direct linkage between steering servo saver and steering obstructs

Balance:

Front/rear fat security adjustable via battery power location

Other

Tires:

Maybe not included

Tires:

Not included

Recommendations:

Full-color guide

Set-up Book:

Printed variation perhaps not included. Latest full-color Set-up guide (16 pages) might arranged from XRAY website. Set-up Book shows past XRAY models in photographs included within it, although methodology and set-up concept are the identical for all 1/12 pan vehicles

Packing:

Carton industry with synthetic bags containing elements

Additionally included:

HUDY Diff Grease, Authentication Certificate, elements list & exploded view, decals, sebum

Not included:

Motor, batteries, are priced at controller, tires, human anatomy, steering servo, radio equipment, tools



Remark :
Due to limited stock availability, please notice that some XRAY items may have to order from the factory and the ready time is around 4-6 weeks. Customer purchases the item is assumed to accept the waiting time which allows us to order directly from the manufacturer if the item is out of our warehouse.
