Proportions |
Course: | 1/12 electric pan car |
Width: | Adjustable 167mm +/- 3mm front part |
Length: | 264 mm (varies relative to back tires used) |
Wheelbase: | 201+/- 0.5mm |
Body Weight: | 205 g |
Ready-to-run fat: | 840 g - incl. BL system (varies decided by gear utilized) |
Framework |
Chassis: | EU version - 2.5mm carbon fiber, CNC machined Usa version - 2.0mm Swiss 7075 T6 aluminum, CNC machined |
Body: | Perhaps not included, makes use of 1/12 pan vehicle kind |
Drivetrain |
Kind: | 2WD direct drive to rear axle |
Straight Back Axle: | Graphite shaft with ball differential |
Main: | Spur / pinion |
Bearings: | High-speed ball-bearings (10) |
Suspension System |
Front Side: | Spring-supported, kingpin-style front suspension system with top & repaid suspension system system arms and steering obstructs |
Straight Back: | Articulating back engine POD adjustable via pivot-ball links, controlled by right back shock absorber |
Back Shock: | Central adjustable oil-filled surprise absorber |
Geometry |
Ride Height: | Adjustable front + backside |
Wheelbase: | Adjustable |
Camber: | Adjustable front side |
Front Caster (Static): | 1â14.5° fixed adjustable fixed caster |
Front Caster (Reactive): | 2.5â7.5° adjustable reactive caster |
Track-width: | Adjustable front component and right back |
Toe: | Adjustable front |
Downstop: | Adjustable rear |
Ackermann: | Adjustable with shims |
Bumpsteer: | Adjustable with shims |
Steering: | Direct linkage between steering servo saver and steering obstructs |
Balance: | Front/rear fat security adjustable via battery power location |
Other |
Tires: | Maybe not included |
Tires: | Maybe not included |
Directions: | Full-color guide |
Set-up Book: | Printed variation perhaps not included. Latest full-color Set-up guide (16 pages) might be create from XRAY site. Set-up Book shows past XRAY models in photographs included within it, however the methodology and set-up concept is the identical for a lot of 1/12 pan automobiles |
Packing: | Carton industry with synthetic bags containing elements |
Additionally included: | HUDY Diff Grease, Authentication Certificate, elements list & exploded view, decals, natural oils |
Maybe not included: | Engine, batteries, speed controller, tires, human body, steering servo, radio gear, tools |
