XRAY 350013 XB8 2018 Specs  [XR-350013]

XRAY 350013 XB8 2018 Specs
Price:
CAD$1,028.20
Brand:
XRAY
Model:
XR-350013
Please kindly input your name and email address, we will inform you once we have the restocking.
Or you may find similar product under the
R/C Models - Off-Road - Buggy - Nitro Powered category
Write a review
alt="XRAY 350013 XB8 2018 Specs" title="XRAY 350013 XB8 2018 Specs"
alt="XRAY 350013 XB8 2018 Specs" title="XRAY 350013 XB8 2018 Specs"
alt="XRAY 350013 XB8 2018 Specs" title="XRAY 350013 XB8 2018 Specs"
alt="XRAY 350013 XB8 2018 Specs" title="XRAY 350013 XB8 2018 Specs"
alt="XRAY 350013 XB8 2018 Specs" title="XRAY 350013 XB8 2018 Specs"
alt="XRAY 350013 XB8 2018 Specs" title="XRAY 350013 XB8 2018 Specs"
alt="XRAY 350013 XB8 2018 Specs" title="XRAY 350013 XB8 2018 Specs"
alt="XRAY 350013 XB8 2018 Specs" title="XRAY 350013 XB8 2018 Specs"
alt="XRAY 350013 XB8 2018 Specs" title="XRAY 350013 XB8 2018 Specs"
alt="XRAY 350013 XB8 2018 Specs" title="XRAY 350013 XB8 2018 Specs"
alt="XRAY 350013 XB8 2018 Specs" title="XRAY 350013 XB8 2018 Specs"
alt="XRAY 350013 XB8 2018 Specs" title="XRAY 350013 XB8 2018 Specs"
alt="XRAY 350013 XB8 2018 Specs" title="XRAY 350013 XB8 2018 Specs"
alt="XRAY 350013 XB8 2018 Specs" title="XRAY 350013 XB8 2018 Specs"
alt="XRAY 350013 XB8 2018 Specs" title="XRAY 350013 XB8 2018 Specs"
alt="XRAY 350013 XB8 2018 Specs" title="XRAY 350013 XB8 2018 Specs"
alt="XRAY 350013 XB8 2018 Specs" title="XRAY 350013 XB8 2018 Specs"
alt="XRAY 350013 XB8 2018 Specs" title="XRAY 350013 XB8 2018 Specs"

Dimension

  • Length: 500 mm
  • Chassis size: 399.5 mm
  • Wheelbase: 322~328 mm
  • Width: 310 mm
  • Weight: 1868 g
  • Approximate working fat: 3205 g


Chassis

  • Chassis: 3 mm CNC-machined Swiss 7075 T6 hardcoated aluminum
  • Radio tray: Composite 1-piece
  • Central diff top deck: Composite
  • Braces: Composite braces (front side component / straight back)


Suspension

  • Suspension: Pivot ball totally adjustable suspension
  • Rear suspension system system system system: Lower H-arm with adjustable top camber link
  • Front suspension system: Lower H-arm with adjustable top camber url A-arm
  • Rear upright: Composite with dual supply mounting and 2 reduced roll center functions and top aluminum supper with 3 top roll center functions
  • Shocks: Big-bore shocks with different shock pistons featuring Delrin pistons
  • Shock towers: Front & rear 4.0mm alu


Drivetrain

  • Type: Full-time shaft-drive 4WD with center differential
  • Primary: metal spur gear / clutchbell
  • Drive shafts: HUDY Spring Steel™ universal drive shafts in-front & CVD in rear
  • Central shafts: HUDY Spring metal™ CVD drive shafts
  • Differentials: Sealed, 6 gear, silicone-filled
  • Clutch: Aluminum 3-shoe
  • Bearings: Rubber-sealed


Gearing

  • Pinion: 14T front component / rear
  • Crown gear: 46T front / rear
  • Clutchbell: 13T
  • Spur gear: 46T


Body, Tires, Wheels & Misc.

  • Body: XRAY XB8 high Speed '16 body
  • Tires: perhaps not included
  • Wheels: not included, standard 17 mm hub
  • Fuel tank: 123cc capability with capacity-adjustment portions, with hypertonic tank lid and inside stone-type drifting filter


Adjustment possibilities

  • Standard modification: Camber, caster, toe-in, wheelbase, kick-up, anti-squat, repaid & top roll facilities, kingpin, Ackermann, bump steer, Multi-Flex, fat balance
  • Items maybe not included
  • engine, Exhaust system, Electronics (broadcast, Receiver, Servos, Batteries), Wheels, Tires, Tools, Wheel device, Receiver battery power, fuel, modification, begin industry, Glow heater, Paint, Charger, Universal product for many peanuts and turnbuckles, Set-up guide.
Remark :
Due to limited stock availability, please notice that some XRAY items may have to order from the factory and the ready time is around 4-6 weeks. Customer purchases the item is assumed to accept the waiting time which allows us to order directly from the manufacturer if the item is out of our warehouse.
