Dimensions |
Class: | 1/10 electric 2WD off road vehicle |
Width: | Adjustable 245-250mm |
Length: | 274mm (394 with wing) |
Wheelbase: | Adjustable 282-285mm |
Bodyweight: | 835g |
Ready-to-run fat: | 1520g |
Chassis |
Chassis: | CNC-machined Swiss 7075 T6 aluminum 2.5mm (carpeting Edition) or 2.0mm (Dirt Edition) |
Front top deck: | Composite extreme (carpeting Edition) or moderate (Dirt variation) |
Suspension |
Suspension: | Adjustable suspension system system via included Suspension System I.S.S. |
Straight back suspension system system: | Lower supply with adjustable top camber url |
Front suspension system system system system: | Lower supply with adjustable top camber hyperlink adequate cause for adjustable caster 0°, 2.5° and 5° |
Straight back upright: | Composite 0° toe-in with twin supply mounting and 7 roll center jobs |
Shocks: | Membrane free surprise absorbers with Delrin pistons |
Shock towers: | Front & right back machined 4.0mm & 3.5 mm laminated carbon graphite (Carpet Edition) or composite (dust Edition) with many shock mounting |
Drivetrain |
Type: | 2WD |
Principal: | Pinion / spur |
Drive shafts: | HUDY Spring Metal CVD drive shafts |
Differential: | Sealed gear differential, 6 gear, silicone-filled |
Slipper clutch: | Adjustable 3-Pad |
Bearings: | Rubber-sealed high-speed bearings |
Gearing |
Primary ratio: | 1:2.65 |
Gear Box gear: | 36T (carpeting Edition) or 25T (dust variation) |
Differential pulley: | 53T |
Spur gear: | 81T (75T, 78T, 84T & 87T option) |
Engine pinion: | Not included |
Geometry |
Camber: | Adjustable front part + backside |
Front Caster: | 26° fixed + caster in caster block = 26°, 28.5°, 31° total caster range |
Toe-in: | Adjustable front + straight back |
Downstops: | Adjustable front component + straight back |
Front kick-up: | Adjustable 26°~31° |
Right back anti-squat: | Adjustable 0°~4° |
Anti-roll pubs: | 1.0mm, 1.1mm, 1.2mm right back (choice just) |
Ackermann: | Adjustable |
Bump steer: | Adjustable |
Steering: | Centrally-positioned dual steering system |
Body, Tires, Wheels & Misc |
Body: | XRAY XB2 body |
Tires: | Perhaps not included |
Tires: | XRAY Aerodisk 12mm Wheel hex hub |
Adjustment Possibilities |
Standard modification: | Camber, toe-in, caster, track width, wheelbase, kick-up, anti-squat, roll center, Ackermann, bump steer |
Guidelines: | Full-color manual with 3D photos (40 pages) |
Set-up guide: | Not included. HUDY 2-color off road set-up guide (40 pages) could be set up in Download component because of this shows 1/8 down road models in photographs included within it. Though the methodology and set-up concept are exactly the same for several contemporary 1/10 down road automobiles. |
Packing: | Carton package with synthetic bags with elements |
In addition included | HUDY Graphite Grease, Silicone natural oils, Authentication Certificate, Parts list & Exploded view, Decals |
Products perhaps not Included |
Radio system (transmitter and receiver), steering servo, engine, pinion gear, LiPo battery pack packages, speed controller, charger, tires, inserts, double-sided tape, CA glue, bearing oil, medium-grade (blue) threadlock, universal product for many peanuts and turnbuckles alongside tools |
