XRAY 320203 - Xray T2D 2019 - 2WD 1/10 Electric Stadium Truck - Dirt Edition  [XR-320203]

XRAY XT2
1/10 DELUXE STADIUM TRUCK 2WD

2018 All-new

• Recent EOS Champion and united states of america Champion platform
• All-in-one concept  includes specific elements to create the XT2 for specific track conditions on either Carpet or Dirt:

- Both types of gearboxes and engine dishes allowing positioning linked to engine in paid destination (Carpet) or top location (Dirt)

- Gear differential (carpeting) and ball differential (dirt)

- Two various hardness of suspension system system system arms: medium (Dirt), difficult (carpeting)

- Two different backside surprise towers: composite (carpeting), graphite (Dirt)

- Both kinds of composite battery power straps to accommodate two various gear containers

- Both forms of composite mounts to find the best brace to match two various gear containers

- Composite gear cover to shield kit package from dirt

• Original smaller front composite framework front side brace allows mounting of new graphite component guard brace to alter front framework flex
• New graphite framework component guard brace for increased security and performance
• New protected steering linkage mounting increases dependability through steering assembly
• New shock absorber paid down shims provide more accurate surprise shaft movement
• New surprise absorber O-rings for better sealing and shock performance
• New suspension system pin washers prevent the suspension system system system pins from striking theaters, increasing dependability

General

• Recent EOS Champion and USA Champion platform
• All-in-one concept  includes specific elements generate the XT2 for many track conditions on either Carpet or Dirt:
• Both kinds of gearboxes and engine meals allowing positioning about the motor in reduced spot (carpeting variation) or top spot (Dirt Edition)
• Gear differential (carpeting Edition) and ball differential (dust variation) included
• Based on ultra-successful XB2 platform
• Full compatibility and interchangeable parts
• Designed for greatest performance anyhow levels of racing
• Engineered with once you understand of smallest details
• Manufactured with prominent imaginative craftsmanship from premium European materials
• EFRA, ROAR, FEMCA spec compliant
• Super a simple task to make, arranged, keep, and drive
• Developed, produced, and styled by European Champion Martin Bayer and Dipl. Eng. Juraj Hudy, produced completely by XRAY in Nations In Nations In Europe on planet's sophisticated RC production facility
• Setting the current standard for premium quality, reliability and performance
• Premium XRAY solution & support

Chassis

• Optimal framework fat blood circulation & balance
• Both kinds of gearboxes and motor meals allowing keeping this engine in repaid location (carpeting Edition) or top position (Dirt Edition)Original XRAY Multi-Flex™ technology for easy framework flex adjustment
• Swiss 7075 T6 hardcoated 2.0mm aluminum framework: lightweight, strong, rigid
• Electronics design allows going the batteries frontwards/rearwards, and utilizing standard or mid-size servos and either utilizing chair pack or short pack batteries
• Composite component guards are significant little bit of the XT2 Multi-Flex™ system
• Shorter front composite chassis front part brace allows mounting of this latest graphite side guard brace to boost front framework flex
• Custom-designed front side reduced framework brace, for sale in moderate and difficult hardness for specific track conditions
• Front safety bumper
• Custom-designed top deck, easily accessible in moderate and hard hardness for particular track conditions
• Swiss 7075 T6 aluminum engine plate
• Both forms of composite battery pack straps to suit two various gear containers with foam spacer
• Lightweight, strong composite surprise towers with many shock mounting jobs (carpeting Edition) & graphite straight back surprise tower (Dirt Edition)
• Pre-drilled centerline holes for effortless balancing because of the HUDY Chassis Balancing Tool #107880

Drivetrain & Differentials:

• Conventional gear-driven 2WD down road arena truck
• Unique gear industry, Gear Box and motor meal with lowered top shaft, forward-shifted engine for improved steering and managing on higher-traction surfaces
• Included right back gear differential with adjustable oil viscosity, 53T gear & inside satellite gears (Carpet Edition)
• Included externally-adjustable ball differential, 53T gear & axial bearings (Dirt Edition)36T (carpeting Edition) & 25T (dirt Edition) graphite composite idler gears
• 20T super-lightweight Swiss 7075 T6 hardcoated aluminum top shaft
• Robust slip-adjustable clutch with 81T primary spur gear molded from exclusive key blend of composite material
• 3-pad slipper clutch with ultra-efficient SLS product for much more efficient & exact slide modification, and HUDY Spring Steel™ hardened outdrives for additional lifespan and reliability
• Constant velocity drives (CVD) are produced from unique HUDY Spring Steel™ for compensated fat and increased durability
• Ultra-lightweight 12mm wheel hex drive hubs CNC-machined from Swiss 7075 T6 and black-coated have in fact really ultra-true hex clamping design which guarantees solid mounting of wheel
• Full band of 22 high-speed, blue-sealed ball-bearings are used through drivetrain to be certain maximum effectiveness, degreased and oiled with AeroShell® Fluid 12 for maximum smoothness and endurance

Suspension

• Integrated Suspension system Settings (I.S.S.) for quick & effortless suspension system system system geometry developing utilizing eccentric bushings devote Swiss 7075 T6 aluminum suspension system system system system holders
• Specially-designed suspension system system system elements created from cautiously developed personalized composite mixtures to make sure appropriate flex and durability
• Race-perfected suspension system system geometry for superior performance and freedom in many competition conditions.
• Suspension fingers can be found in moderate, hard and graphite hardness for particular track conditions
• Suspension elements: steering obstructs, caster obstructs and uprights are available in medium and difficult hardness for specific track conditions
• Lower composite supply install with built-in 26° kick-up angle; optional aluminum and metal supply mounts available
• Lightweight, rigid caster obstructs can do various fundamental caster views utilizing included caster bushings
• Tiny yet tough steering obstructs comprises composite steering obstructs + graphite Ackermann extensions
• Adjustable fat security & wheelbase via included shims on outside suspension system system pins
• Compact straight back uprights with 0° toe and 6 different top roll center positions
• HUDY Spring Steel™ product for turnbuckles (featuring a tougher core) is necessary for front part & rear upright linkages, and steering system.
• Front anti-roll club made from unique spring steel item to aid the automobile at front component is initiated towards leading human anatomy mount & might be just modified via linkages; laser-engraved markings for simple recognition, easily accessible in various sizes for fine-tuning
• Optionally available back anti-roll club set to help a large part connected with vehicle; efficiently modified via linkages; laser-engraved markings for simple recognition, easily obtainable in several sizes for fine-tuning
• Suspension pin washers stop the suspension system system system pins from released, increasing dependability

Steering

• Simple yet effective dual-arm steering system
• Secure steering linkage mounting increases dependability of steering assembly
• Fully bearing-equipped with 8 high-speed ball-bearings for extremely precise steering
• Easily-adjustable Ackermann by fast transforming the steering link mounting jobs regarding steering plate
• Bump guide modification for far more aggression
• Ackermann modification via included shims or using different graphite expansion dishes on steering obstructs

Shocks

• constant, dependable, membrane-free shocks with bleed-screw surprise limitation design function up-stop & downstop modification via shims (under shock collar, and under pistons, correspondingly)
• Swiss 7075 T6 aluminum surprise systems, paid nut & bleeder shock caps
• Super-precise molded Delrin™ pistons can be had with 2-hole & different diameters (1.6mm & 1.7mm) for precise surprise modification, for personalized modification, a build up blank pistons (no holes) may also be included
• Shock rods are machined from a particular steel item, precision hand-ground for maximum smooth procedure as well as hardened for increased lifespan
• Premium surprise springs created especially to match the XT2 shocks; manually determined, chosen and matched into pairs to make certain equal size and damping traits; laser etched for easy identification
• Full form of linear -or- modern surprise springs available
• Premium silicone sebum laboratory tested and calibrated to be certain maximum determination and quality

Body, Wings, Wheels:

• High-downforce, low-profile aerodynamic Lexan™ human body made to completely fit the XT2, features high-downforce areas (including front display screen and top roof motion systems) for appropriate venting, and component downforce areas for greater safety.
• Tough composite component guards work double-sided Velcro™ tape to seal your body completely towards framework and seal against dirt.
• Effective straight back wing completed up being made to work completely utilising the XRAY XT2 body. Created from strong Lexan™ product, the wing is supported on wing mounts by additional flat shims to elevated help and expand residing in regards to the wing.
• Specially produced 12mm hex hub tires for high-competition competition; featuring reinforcement ribs to get rid of deformation and molded from really versatile item to retain type despite having effects (available as choice just)

Assembly, Set-up & help:

• Premium 3D full-color guide & extra sheets
• To totally understand the set-up opportunities we suggest typically the most popular HUDY Set-up Book which can be saturated in over 40 pages of top-notch images and easy-to-read RC vehicle set-up explanations
• Exclusive Virtual online Setup Sheet database with and endless choice of set-up sheets for battle tracks through the complete world
• Premium, unmatched XRAY on the web support

Adjustment possibilities:

• Fully-adjustable front component and back suspension system system system system geometry: caster, camber, back toe, kick-up, anti-squat, ride height, downstops, track-width, roll center, wheelbase, Multi-Flex™
• Adjustable right back differential action
• Adjustable slipper clutch
• Adjustable HUDY Sprint Steel™ turnbuckles (steering, front & straight back top links)
• several upper & paid back shock mounting areas at front & rear
• Adjustable Ackermann and bumpsteer
• Adjustable front part anti-roll bar
• Optional adjustable back anti-roll bar
• Chassis pre-drilled holes for fat protection modification
